Whale Orca Automatic Electric Bilge 1300Gph 12V

Compact, powerful and automatic.

The large footprint of this submersible bilge pump ensures no separate bilge switch is required due to the maximum surface area exposure to bilge water.

Features

• Integrated Electronics – Built-in fully potted IC (intelligent control)
• Sealed microprocessor electronics for water ingress protection
• Fully Protected – Robust, fuel resistant ABS housing
• Easy Instal – Stepped connection ports to suit 25mm (1″) and 28mm (1 1/8″) installations
• Efficiency – Maximum area is exposed to bilge water due to large surface area

Benefits

• Latest addition to the Intelligent Control bilge pump range
• High performance flow rate of 1300 US gals/hour
• Easily installed with automatic sensor built in
• Separate bilge switch not required
• Extensive battery life, low amp draw
• Fits neatly in compact bilge areas
• Fuel resistant ABS housing
• Efficient – maximum surface area exposed to bilge water due to large filter

Awards & Accreditations

• Conforms to ISO 8849
• CE certified

Specifications

• Nominal Voltage: 12V D.C.
• Open Flow Rate: 1300 US GPH (82 l/min) at 13.6V D.C.
• Flow Rate at 1m (3ft) Head: 1100 GPH (65 l/min)
• Current Draw: 5 Amps
• Recommended Automotive Fuse Size: 7.5 Amp
• Weight: 0.9kg (2lbs)
• Hose Connection: 25mm (1″) and 28mm (1 1/8″) stepped ports
• Wire Size: 16 AWG x 1m (3ft)
• Maximum Discharge Head: 4.5m (14.8ft)
• Overall Height: 129mm (5.1″)
• Overall Width: 168mm (6.6″)
• Overall Depth: 121mm (4.8″)

Materials

• Pump Body: ABS
• Seals: Nitrile
• Impeller: Acetal
