Whale Supersub 500 Bilge Pump 12V

High capacity, narrow, low profile submersible bilge pump. Designed to be used with a separate bilge switch.

Low profile electric bilge pump perfect for narrow bilge spaces. Supersubs fit where other pumps won’t in small or awkward bilge spaces.

Features

• Drains to down 9mm (1/3″)
• Simple Plumbing
• Rotate ports to suit your installation.
• Reliable Long Term
• Includes extra long wires for integirty
• Versatile Installation
• Multi-position pump body and head
• Easy Maintenance
• Unique strainer easily cleaned
• Efficient Operation
• Low profile strainer
• Integrated Bleed Ball
• Prevents airlocks

Benefits

• Low narrow design for confined bilge spaces
• Simple to install – rotate outlet and pump body to suit installation.
• High performance
• Efficient operation – power consumption very low
• Easily cleaned – snap fit assembley
• Low profile strainer – leaves bilge almost dry

Tips

• It is important to ensure that the system incorporates a vented anti-syphon loop

Awards & Accreditations

• PBO’s Tester Choice
• CE certified

Approvals & Standards

• Conforms to ISO 8849 and ISO 15083
• Ignition protected under ABYC and USCG standards
• EMC compliant. NMMA type accepted.

Specifications

• Open Flow Rate: 500 US GPH (32 Litres/min) at 13.6V D.C.
• Flow Rate at 1m (3ft) Head: 400 US GPH (25 Litres/min)
• Nominal Voltage: 12V D.C.
• Current Draw: 2.4 Amp
• Recommended Fuse Size (Automotive): 5 Amp
• Weight: 270g (0.6lbs)
• Hose Connections: 19mm (3/4″)
• Minimum Wire Size: 1.5mm² (16 AWG)

Materials

• Pump Body: Polypropylene, High Temperature ABS
• Locking Ring: Acetal
• Impeller: Glass-Filled PBT
• Seals: Nitrile
• Fasteners: Stainless Steel

Materials in Contact with Fluid

• Polypropylene
• ABS
• Glass-Filled PBT
• Nitrile
