The original choice of bilge pump for extreme sailing conditions.
Durable diecast alloy bilge pump. Top performance – 65 litres (17 US gals) minute. The robust design will withstand even the toughest marine conditions.
Features
- Easy grasp handle
Easy Maintenance
- Designed to be accessed instantly
Simple Plumbing
- 38mm (1 1/2″) smooth hose connections
High Flow Non-Choke Valves
- No filter to block or clean
Mounting Options
- On deck option
Benefits
- Toughest marine conditions are no match for the robust design.
- Top Performance – 65 litres (17 US gals) per minute
- On Deck and Bulkhead mounting options
- Designed to be easily installed and maintained
- Efficiency – large non-choke valves
- Perfect for workboats, cruisers and offshore racing
- Easy pump action – self-priming
- Typical use: Bilge pump out / holding tank pump out
Awards & Accreditations
- In accordance with ISO15083, a suitable primary bilge pump on boats equal to or greater than 12m (40ft)
Specifications
- Weight: 2.3kg (5lbs)
- Hose Connections: 38mm (1 1/2″) smooth hose connections
- Maximum Suction Lift: 4m (13.5ft)
- Maximum Discharge Head: 4m (13.5ft)
Materials
- Pump Body: Marine Grade LM6 Aluminium Alloy (Epoxy Coated)
- Diaphragm: Neoprene
- Fasteners: Stainless Steel
Materials Contact with Fluid
- Marine Grade LM6 Aluminium Alloy (Epoxy Coated)
- Neoprene
- Nitrile
- Stainless Steel
Performance Data
- Suction Lift: 1m (3ft) – 2m (6ft)
- Discharge Head: 0.5m (1.5ft)
- 45 Strokes per Minute: 41 Litres (11 US gals)
- 70 Strokes per Minute: 65 Litres (17 US gals)
